SETUP INSTRUCTIONS
INSTALLING/REPLACING THE BATTERY
The HT08 uses a 3.6VDC “1/2 AA” Lithium-ion battery.
To open the battery compartment, use a paper clip or a
screwdriver with a fine point to push in the silver flange
showing through the small square hole in the rear of the unit
(left photo above). Push back the cover (middle photo),
remove the old battery (right photo) and insert a fresh battery
in the
correct orientation. Then replace the cover, pushing it
forward until you feel and hear a click.
Whenever you change the battery, each of the two LEDs will
flash red once, and then green once.
Note: If the battery is removed from a unit before it has been
set up from software or while it is recording, the unit must be
reconfigured before it can be reactivated. If it is not
reconfigured, the unit will rem
ain in standby mode.
INSTALL SOFTWARE AND DRIVERS
1. Place mini-disc in tray of CD/DVD drive, shiny side down.
Close tray.
2. When the AutoPlay window appears, click on “Open folder
to view files using Windows Explorer.”
3. Windows Explorer will indicate that there are two “Files
Currently on the Disc”. One is actually a folder containing
a PDF of the HT08
08
user’s manual (as well as PDFs of the
manuals for
the HT20 and HT50_larger versions of the HT
7
