USAGE OF ROOM THERMOSTAT
HT300 is a wired room thermostat. HT300 room thermostats are used in heating systems to keep the room
temperature constant at the set temperature.
Large LCD Backlight Display
Touch Keys
Daily and Weekly Program
Different Mode Options (Comfort, Economy, Holiday)
Battery Indicator, Key Lock, Heating Calibration
For heating systems
ON/OFF control
Battery DC 3 V (2 × 1,5V AAA Alkaline battery)
USAGE AREAS
Houses
Apartments
Residences
Schools
Offices
The device can be used on combi boilers and on all on/off heating systems operating at 30V DC 2A current and
voltage values.
MECHANICAL DESIGN
The device consists of 3 part:
Plastic body
Battery cover
Wall hanger
The battery cover is attached to the plastic case. After the wall bracket is mounted in the wanted area, the plastic
body is attached to the wall bracket.
Room Thermostat Buttons Functions
generallife.com.tr2 / 9
1.
2.
3.
4.
5.
6.
Weekly Program Button
Temperature Adjustment (To Increase)
Settings Button
Temperature Adjustment (To Decrease)
Mode Button
On/Off Button
3
1
2
4
5
6
To Next Page
