NO. PART NO. NAME: DESCRIPTION MACH.
1 23-SM-6149 BASE 1
2 01-SM-6150 PLATFORM CARRIAGE. 1
3 08-SM-6063 SPRING: CARRIAGE REAR 1
4 08-SM-1337 WASHER: PLATFORM SHAFT 2
5 06-SM-1259 WASHER: RUBBER 2
6 09-SM-6065 SHAFT: PLATFORM CARRIAGE 1
7 08-SM-6064 SPRING: CARRIAGE FRONT 1
8 08-SM-6120 SCREW: CSK SOC HD 6MA X 30 2
9 09-SM-6067 RAIL: PLATFORM CARRIAGE 1
10 09-SM-1301 REGULATOR CAM: 30MM 1
11 01-SM-6152 REGULATOR BRACKET 1
12 08-SM-6153 SPRING: REGULATOR BRACKET 1
13 08-SM-1035 SCREW: SET 8MA X 8 1
14 08-SM-6070 CAM FOLLOWER 1
15 08-SM-6118 SCREW: SET 5MA X 6 1
16 08-SM-6072 BUSHING: REGULATOR KNOB 1
17 09-SM-6138 KNOB: REGULATOR 1
18 09-SM-6144 KNOB: SPEED CONTROL 1
19 08-SM-6019 INDICATOR PIN 1
20 08-SM-6155 SPRING: AUTO ENGAGEMENT SHAFT 1
21 09-SM-6156 SHAFT: AUTO ENGAGEMENT 1
22 06-SM-6157 ROLLER: AUTO ENGAGEMENT 1
23 08-SM-1080 NUT: HEX 6MM 1
24 08-SM-6075 SCREW: HXHD 6MA X 30 NYLON 1
25 08-SM-6076 WASHER: STAR 6MM 1
26 08-SM-6077 SCREW: SET 10MA X 20 2
27 08-SM-1304 SCREW: SET REGULATOR CAM 1
28 08-SM-1102 WASHER: FLAT 6MM 2
29 09-SM-6158 BUSHING: PLATFORM ROLLER 1
30 06-SM-6159 ROLLER: PLATFORM 1
31 08-SM-1282 SCREW: HXHD 6MA X 25 1
32 08-SM-1488 SCREW: SL PHLHD 6MA X 8 2
33 23-SM-6160 PLATFORM BRKT 1
34 04-SM-6161 PLATE: PLATFORM BRKT 1
35 08-SM-1506 SCREW: HXHD 8MA X 20 2
36 04-SM-1489 BRACKET: FOOD PUSHER 1
37 08-SM-6080 SCREW: HXHD 6MA X 10 2
38 08-SM-6081 PIVOT PIN: PLATFORM 1
39 08-SM-1514 WASHER: STAR 8MM 2
40 09-SM-1274 KNOB: PLATFORM 1
41 09-SM-6082 HANDLE: PLATFORM 1
42 23-SM-1491 PLATFORM: SMA12 1
43 08-SM-6163 SPACER: MOTOR MOUNT 1
44 06-SM-1487 WASHER: RUBBER 3
45 04-SM-1484 SHAFT: FOOD PUSHER 1
46 23-SM-1481 FOOD PUSHER ASSY 1
47 09-SM-1482 SHAFT: THREADED (HNDL ATTCH) 1
48 04-SM-1714 PLATE: FOOD PUSHER STOP 1
49 06-SM-1263 NYLON RIDER 7
50 09-SM-1483 HANDLE: FOOD PUSHER (W/SET SCREW) 1
50a 23-SM-1480 FOOD PUSHER ARM 1
51 30-SM-6164 MOTOR ASSY: 115V/60HZ 1
MOTOR: 220V/50HZ 1
52 08-SM-6165 ROD: MOTOR ADJUSTING (FORMED) 1
53 08-SM-6127 WASHER: STAR 5MM 2
54 08-SM-6128 SCREW: SET 6MA X 10 CONE PT 1
55 08-SM-1885 NUT: HEX JAM 8MM 1
56 06-SM-6091 BELT: TB2-345 1
57 30-SM-6093 KNIFE PULLEY ASSY (INC: 57-60) 1
58 08-SM-1026 RETAINING RING: INTERNAL 35MM 1
59 09-SM-1027 BEARING: #6202-2RS (CALL FACTORY) 2
60 09-SM-1028 BEARING SPACER 1
61 08-SM-6166 SCREW: CSK 5MA X 8 SS 2
62 06-SM-6094 COVER: BELT 1
63 09-SM-6001 KNIFE: 12" 1
64 08-SM-6096 SPACER: COVER PULLEY 1
65 08-SM-1032 SCREW: CSKHD 5MA X 10 SS 1
66 23-SM-6167 KNIFE COVER 1
67 08-SM-6168 STUD: KNIFE COVER POSITIONING 1
68 06-SM-6169 SLEEVE: KNIFE COVER POSITIONING 1
69 04-SM-6170 BRACKET: MOTOR ADJUSTING ROD 1
70 08-SM-6171 SCREW: HXHD 8MA X 65 2
71 08-SM-1010 WASHER: FLAT 8MM 3
72 08-SM-6172 SPACER: MOTOR MOUNT 2
73 08-SM-6173 SCREW: SET 6MA X 10 2
74 04-SM-6102 KNIFE WIPER 1
75 08-SM-1515 NUT: HEX 8MM 1
76 08-SM-6174 SCREW: THUMB KNIFE WIPER 2
ROD: KNIFE COVER (5MA X 235) KNOB: 1
77
78
09-SM-6103
09-SM-1208
SHARPENER HSG/KNIFE COVER 1
79 04-SM-6175 SHAFT: REGULATOR, REAR 1
80 04-SM-6176 SHAFT: REGULATOR, FRONT 1
81 23-SM-6177 SUPPORT: REGULATOR PLATE 1
82 08-SM-6107 SCREW: HXHD 8MA X 50 SS 2
83 08-SM-1282 SCREW: HXHD 6 MA X 25 SS 2
84 23-SM-6178 REGULATOR PLATE 1
KEY
NO. PART NO. NAME: DESCRIPTION MACH.
85 23-SM-6179 SHARPENER BRACKET 1
86 08-SM-1091 SCREW: SET 6MA X 8 1
87 08-SM-1102 WASHER: FLAT 6MM 1
88 08-SM-1282 SCREW: HXHD 6MAX 25 1
89 08-SM-6180 PLUG: SHARPENER BRACKET 1
90 30-SM-1207 MTG POST ASSY: SHARPENER 1
91 23-SM-1202 TUBE: SHAFT, NUT & FRAME 1
92 30-SM-1202 SHARPENER & FRAME ASSY 1
93 08-SM-1322 SPRING: SHARPENING STONE 1
94 08-SM-1323 SPRING: DEBURRING STONE 1
95 09-SM-1317 SHAFT: DEBURRING STONE 1
96 09-SM-1318 SHAFT: SHARPENING STONE 1
97 09-SM-1327 DEBURRING STONE 1
98 06-SM-6051 FIBER WASHER 2
99 08-SM-6050 NUT: STONE MOUNT 2
100 09-SM-1722 MTG CLIP: DEBURR BUTTON 1
101 23-SM-1722 BUTTON: DEBURRING STONE 1
102 09-SM-1203 STONE: SHARPENING 1
103 08-SM-1012 SCREW: PNHD 4MAX 10 2
104 08-SM-1204 WASHER: FLAT 4MM 2
105 08-SM-1336 RETAINING RING: STONE SHAFT 1
106 09-SM-1208 KNOB: SHARPENER HSG/KNIFE COVER 1
107 08-SM-1211 NUT: TUBE SHAFT 1
108 08-SM-1336 RETAINING RING: STONE SHAFT 1
109 23-SM-1320 SHARPENER HOUSING 1
110 30-SM-1320 SHARPENER ASSY COMPLETE 1
111 08-SM-1210 SCREW: CSKHD 6MAX 12 1
112 08-SM-1204 WASHER: FLAT 4MM 1
113 08-SM-6181 SCREW: SL PHLHD 4MA X 12 1
114 09-SM-6182 BUSHING: STEP 1
115 08-SM-1055 WASHER: FLAT 6MM 1
116 08-SM-6183 SCREW: HXHD 6MA X 12 1
117 08-SM-6184 CAM: AUTO ENGAGEMENT 1
118 04-SM-6185 BRACKET: AUTO ENGAGEMENT 1
119 08-SM-6186 SCREW: SOC HD 6MAX 14 2
120 23-SM-6187 CAM MTG BKT ASSY 1
121 08-SM-6188 WASHER: BELVILLE 6MM X 18MM X 0.4 1
122 08-SM-1006 SCREW: SET 6MA X 6 1
123 08-SM-1594 LEVER: ENGAGEMENT 1
124 08-SM-6189 SCREW: SET 5MA X 12 1
125 08-SM-1077 NUT: HEX JAM 5MM 2
126 08-SM-6190 SCREW: SET 6MAX 12 2
127 08-SM-1016 NUT: HEX JAM 6MA 2
128 08-SM-1006 SCREW: SET 6MA X 6 1
129 08-SM-6191 SCREW: HXHD 6MA X 6 1
130 08-SM-6076 WASHER: STAR 6MM 1
131 05-QSM-756 CORDSET 1
132 05-SM-1506 STRAIN RELIEF 1
133 08-SM-6162 WASHER: WAVE 1
134 08-SM-6192 WASHER: SLIP 11MM X 20MM X 0.5MM 1
135 06-SM-6242 NYLON RIDER 2
136 23-SM-1554 ADJUSTMENT FENCE 1
137 09-SM-1564 KNOB: ADJUSTMENT FENCE 1
138 09-SM-1490 KNOB: FOOD PUSHER SHAFT 1
139 08-SM-1251 STUD: PLATFORM BKT 10MM X 38 1
140 08-SM-1010 WASHER: FLAT 8MM 2
141 09-SM-6193 LABEL: CONTROL 1
142 08-SM-6194 SCREW: CSKHD 3 MA X 20 2
143 08-SM-6195 WASHER: STAR 3MM 2
144 08-SM-6196 NUT:HEX3MM 2
145 04-SM-6197 BRACKET: JUNCTION BOX MTG 1
146 09-SM-6198 CAP: CARRIAGE SHAFT COVER 1
147 08-SM-6199 SCREW: RDHD PH 3MAX 15 SF TP 2
148 08-SM-1514 WASHER: STAR 8MM 1
149 08-SM-1515 NUT: HEX 8MM 1
150 08-SM-1761 SCREW: HXHD 8MA X 35 BRASS 1
151 08-SM-6076 WASHER: STAR 6MM 2
152 08-SM-1080 NUT: HEX 6MM 2
153 08-SM-1062 SCREW: HXHD 6MA X 20 BRASS 1
154 08-SM-6200 SCREW: SL SET 6MAX 12 BRASS 1
155 05-SM-6145 SPEED CONTROL: SMA12L 1
156 05-SM-6146 SWITCH BODY: SMA12L 1
157 05-SM-6154 LAMP: SWITCH 1
158 05-SM-6201 SWITCH: (3) BUTTON 1
159 30-SM-6147 SWITCH ASSY: SMA12L 1
(INC:156-159) 1
160 05-SM-6202 BLOCK: JUNCTION 1
161 05-SM-6203 PLUG: GROUND 1
162 05-SM-6204 PLUG: MOTOR LEAD WIRE 1
163 05-SM-6122 CAPACITOR: 20mf, 450V 1
CAPACITOR: 10mf, 450V 1
164 08-SM-1102 WASHER: FLAT 6MM 1
General Slicing/Red Goat Disposers •1152 Park Avenue • P.O. Box 428 • Murfreesboro, TN 37133-0428 • (615) 893-4820
