General SMA12L - Page 15

REPLACEMENT PARTS LIST MODEL:
SMA12L
KEY
QTY
NO. PART NO.
NAME: DESCRIPTION MACH
165 09-SM-1638 KNOB: LIFT LEVER 1
166 08-SM-6205 STUD: SLTD 8MAX 25 1
167 09-SM-6206 LEVER: LIFT 1
168 08-SM-6207 SCREW: HXHD 8MA X 30 SS 1
169 08-SM-6208 BUSHING: LIFT LEVER 1
170 08-SM-6209 STUD: LIFT ROLLER 1
171 08-SM-6210 BUSHING: LIFT ROLLER 1
172 08-SM-1010 WASHER: FLAT 8MM 2
173 09-SM-1632 ROLLER: LIFT LEVER 1
174 08-SM-1885 NUT: JAM HEX 8MM 1
175 30-SM-6211 BLOCK & PIN ASSY: LIFT LEVER 1
176 08-SM-1506 SCREW: HXHD 8MA X 20 2
177 08-SM-6212 SCREW: PNHD 3MAX 15 2
178 08-SM-6196 NUT: HEX 3MM 4
179 08-SM-6195 WASHER: STAR 3MM 2
180 30-SM-6196 BASE ASSY: SMA12L 1
181 08-SM-6107 SCREW: HXHD 8MA X 50 SS 2
182 08-SM-1010 WASHER: FLAT 8MM 2
183 08-SM-6213 SPACER: MTR MT PLATE 2
184 08-SM-1514 WASHER: STAR 8MM 2
185 08-SM-1515 NUT: HEX 8 MM 2
186 08-SM-6119 SCREW: CSK SOC HD 6MA X 16 2
187 08-SM-6214 SPACER: HEX W/THD 2
188 30-SM-6215 MOTOR: 115V 1
189 08-SM-1271 SCREW: HXHD 5MAX 15 3
190 08-SM-6216 SCREW: CSK SOC HD 6MA X 20 5
191 08-SM-1016 NUT: JAM HEX 6MM 4
192 08-SM-6076 WASHER: STAR 6MM 4
193 08-SM-6217 WASHER: CSK 6MM 1
194 30-SM-6218 GEAR BOX ASSY 1
195 04-SM-6219 PIVOT ARM ASSY 1
196 08-SM-6220 KEY: PIVOT ARM 1
197 08-SM-6221 WASHER: SLIP 14MM X 23MM X 0.3MM 1
KEY
QTY
NO. PART NO.
NAME: DESCRIPTION MACH
198 08-SM-6222 PIVOT PIN: CONNECTOR ARM 1
199 08-SM-1582 RETAINING RING: EXT 10MM 2
200 08-SM-1010 WASHER: FLAT 8MM 2
201 08-SM-6223 RETAINING RING: 8MM 2
202 08-SM-6224 BEARING: BRONZE SLEEVE 2
203 04-SM-6225 ARM: CONNECTING 1
204 08-SM-6226 SCREW: PNHD 4MA X 8 1
205 08-SM-1204 WASHER: FLAT 4MM 1
206 08-SM-6227 BEARING: BRONZE FLANGE 2
207 04-SM-6228 BAR: OSCILLATION ARM RET 1
208 08-SM-6229 SPACER: BAR 2
209 08-SM-6230 SCREW: SOC HD 8MAX 35 2
210 08-SM-1514 WASHER: STAR 8MM 2
211 08-SM-1515 NUT: HEX 8MM 2
212 08-SM-6231 INSERT: THREADED 1
213 04-SM-6232 OSCILLATING ARM 1
214 08-SM-6233 ENGAGEMENT BRACKET 1
215 08-SM-1016 NUT: JAM HEX 6MM 3
216 08-SM-6076 WASHER: STAR 6MM 3
217 08-SM-6216 SCREW: CSK SOC HD 6MAX 20 2
218 08-SM-6234 SCREW: HXHD 6MA X 30 1
219 08-SM-1055 WASHER: FLAT 6MM 1
220 09-SM-6235 ROLLER: PLATE CONTACT 1
221 08-SM-6236 BUSHING: SLEEVE BRONZE (6MM) 1
222 23-SM-6237 PLATE: GEAR BOX MTG 1
223 23-SM-6238 PLATE: BTM COVER ATTACH 1
224 04-SM-6239 BOTTOM COVER 1
225 06-SM-1695 FOOT 4
226 08-SM-6240 SCREW: PNHD 5MA X 12 6
227 08-SM-6241 SCREW: PNHD 6 MA X 14 6
228 08-SM-1055 WASHER: FLAT 6MM 5
229 05-SM-6148 CONTROL BOX: SMA12L 1
