3.3 Buttons description and operation
3.3.1 Power ON/OFF and Reset button
When the instrument is OFF, to turn it ON press and hold the Power ON/OFF
/ Reset’ button until the unit turns on (in approximately 1 second).
When the instrument is ON, to turn it OFF press and hold the Power ON/OFF
/ Reset’ button until the display turns OFF (in approximately 3 seconds).
When the instrument is ON, press momentarily the Power ON/OFF / Reset
button to reset the Maximum and Minimum and capture values.
Note: To extend battery life, the TA500 will automatically turn OFF after 3 minutes
of being idle (i.e. no button pressed and no input signal). Turning the unit off
manually, when not in use will prolong battery life.
3.3.2 Ignition System button
Press the Ignition System’ button to select the ignition system measuring
mode that matches the ignition system used in the engine being diagnosed,
as explained below. The selected setting will be shown on the display.
SPW (Spark Plug Wire): Use this setting for all ignition systems equipped
with high voltage spark plug wires (e.g.: Conventional distributor, magneto,
distributorless or waste spark ignition systems).
COP (Coil On Plug): Use this setting for ignition systems in which the ignition
coil is mounted near or directly on top of the spark plug.
3.3.3 Engine Cycles button
Engine
Cycles
Press the Engine Cycles’ button to select the number of cycles for the engine
under measurement. Each time the button is pressed the number of cycles
will change between 2 cycles, 4 cycles, and DIS settings. The selected setting
will show on the display.
For SPW (Spark Plug Wire) measurements mode, it can be set to : 2 or 4
cycles or DIS (Distributorless or waste spark ignition system).
• For COP (Coil on Plug) measurement mode, it can be set to: 2 or 4 cycles.
3.3.4 Main Function / Calibrate button
Press this button to change which measurement is shown in the main (large)
display. There are three measurements to choose from: RPM, spark burn
time, and spark KVolt. Every time this button is pressed momentarily the
measurement changes from one function to the next.
Press and hold this button for three seconds to start the automatic calibration of
the unit to the COP module type being measured. While calibrating, the display
will fl ash “CAL” and will return to normal after the procedure is completed (in
about 3 seconds). Calibration is disable when in SPW mode.
