DESCRIPTION
13
Operation instruments
18. Clutch lever
19. Left handlebar switches
20. Speedometer unit
21. Main switch/steering
22. Right handlebar switches
23. Throttle grip
24. Front brake lever
18
24
20
21
22
23
19
