Generic TR 125 - Lighting & Fuel System Checks

CHECKING/ MAINTAINING
41
When you need to adjust the head-
light turn in or turn out the adjusting
screw (9).
Front and rear turn signal lamp
,I WKH IURQW RU UHDU WXUQ VLJQDO OLJKW
(10) does not glow contact a dealer
to check the electrical circuit or to
replace the lamp.
Tail/brake light and license plate
lamp
,f the tail/brake light (11) and the
license plate light (12) do not glow
disassemble the bolts (1 and 2) for
changing the bulb.
Injection system
The injection system consists afuel
SXPSZLWKWXEHVDIXHO¿OWHUDQGWKH
injector.
)XHOSLSHVVKRXOGQRWEHEHQW
curved or compressed.
Fuel pump
The fuel pump module supplies fuel
to the engine at system pressure.
1
1
2
4
3
9
8
5
6
7
7
2
10
10
11
12
10
10
CAUTION
