Genesis 12t User Manual

10
1010
10
~ÄëçäìíÉ=ÑáÇÉäáíó™
Do not connect BOTH single-ended and balanced inputs to the S2/12t
at the same time. You could over-drive the built-in amplifier, and void
the warranty.
Phase Switch
There are many power amplifiers that invert the phase of the incoming
signal. If you have one of these, and you are also using the line-level
inputs from your preamp, you will have to invert the phase of the
S2/12t. Push the switch down to 180º.
Please note that if you have a phase inverting power amplifier and
have inverted the phase on the S2/12t, AND you are using both line-
level and speaker-level inputs, you must invert the phase of the
speaker-level inputs. Connect the +ve speaker lead to the –ve input
terminal on the S2/12t, and connect the –ve speaker lead to the +ve
input terminal.

Genesis 12t Specifications

Audio Specifications

frequency response	20Hz to 120Hz +/- 1dB
extended frequency response	16Hz to 180Hz -3dB, +2dB

Ports & Interfaces

high-level inputs	left and right with 5-way binding posts
low-level inputs	left and right, single-ended RCA and balanced XLR
LFE low-level mono inputs	single-ended RCA and balanced XLR

Weight and Dimensions

dimensions	31” x 21” x 16” (w x h x d)
dimensions_metric	533mm x 787mm x 406mm
weight	83.5 lbs (38 kg)
