Genesis GMSDR1015LC User Manual

English
10" Sliding Compound Miter Saw
Operator’s Manual GMSDR1015LC
8
KNOWING YOUR MITER SAW
1. Handle
2. Lock-Off Switch
3. Trigger Switch
4. Motor
5. Carrying Handle
6. Upper Blade Guard
7. Lower Blade Guard
8. Rear Carrying handle
9. Dust Bag
10. Sliding Rails
11. Slide Lock Knob
12. Fence
13. Hold Down Work Clamp
14. Table Extension
15. Extension Lock Knob
16. Base
17. Miter Table
18. Miter Angle Pointer
19. Throat Plate
20. Detent Lever
21. Bevel Scale
22. Miter Lock Handle
23. Laser
24. Saw Head Lock Pin
25. Bevel Lock Handle
26. Dust Port
27. Blade
28. Spindle Lock Button
29. Miter Scale
30. Laser Battery Compartment
31. Rear Support Foot
17
12
23
10
7
4
8
21
6
5
2
3
1
18
16
15
14
13
11
14
22
20
19
9
29
FIG 1
25
31
27
30
28
24
26

Genesis GMSDR1015LC Specifications

General

Brand	Genesis
Model	GMSDR1015LC
Category	Saw
Language	English
