FEATURES AND CONTROLS
Quick Reference Guide I 04
03 I Quick Reference Guide
GENESIS GV80
FRONT SEAT ADJUSTMENT
2
Forward and backward
1
Seat cushion length
(for driver’s seat)
Seat cushion support
(for driver’s seat)
2
2
Seatback angle
3
Seat cushion height
1
Lumbar support
Ergo-Motion seat (if equipped)
4
Seat bolster adjustment (for driver’s seat)
5
1
3
4
5
HEADREST ADJUSTMENT
To Raise Headrest:
Pull headrest up.
To Lower Headrest:
Press lock button while pressing
down on headrest.
To adjust headrest forward
(front seats only):
Pull forward to 1 of 3 positions.
To adjust headrest rearward
(front seats only):
Pull it fully forward to the farthest
position and release it.
To Store Settings
1. Shift to P (Park) while the Engine
Start/Stop button is in the ON
position.
2. Adjust the driver’s seat position,
outer side view mirror position,
steering wheel position,
instrument panel illumination
intensity and head-up display
height/brightness to the desired
position.
DRIVER POSITION MEMORY SYSTEM
NOTE: Transmission must be in P (Park).
NOTE:
To reset the system,
please refer to the Owner’s
Manual.
To Recall
Press the desired memory button (1 or 2). The system will beep once.
3. Press the SET button. The system will beep once and notify you ‘Press
button to save settings’ on the cluster LCD display.
4. Press one of the memory buttons (1 or 2) within 4 seconds. The system
will beep twice when the memory has been successfully stored.
5. ‘Driver 1 (or 2) settings saved’ will appear on the cluster LCD display. The
message appears only for the driver’s seat position memory setting.
Ergo-Motion seat automatically
adjusts the driver seat during long
drives. Select seat settings on the
infotainment settings screen to
activate.
