Genesis GV80 Simple Manual

12
ENG
Common
Power Supply DC 14.4 V
Operation Power DC 9 ~ 16 V
Current Consumption Max. 6 A
Dark Current
(average)
Max. 1 mA
Operating
Temperature
-20 ~ 70 °C
Storage Temperature -40 ~ 85 °C
Dimensions
(HeadUnit)
232 (W) x 85.2 (H) x 164.5
(D) mm
Weight (Headunit) 1.4 kg
Front
Monitor
Screen Size (Outline
Dimension)
361.82(H) x 112.4(V) x
12.8(D) mm (Typ.), (W/
PemNut, W/Cover Glass 1.1T)
Resolution 2560 x 720 (14.5”)
Operating Method
TFT, In Plane Switching (IPS),
Active Matrix
Viewing Angle 80/80/80/80 (L/R/U/D)
Internal Lighting LED
Radio
AM
Tuning Range 522 ~ 1620 Khz
Usable Sensitivity 35 dBuV
SNR Ratio 45 dB
FM
Tuning Range 87.5 ~ 108.0 Mhz
Usable Sensitivity 10 dBuV
SNR Ratio 50 dB
DAB
Tuning Range 174.928 ~ 239.200 Mhz
Min. Sensitivity -100 dBm
Adjacent Channel
Selectivity
60 dBc
Far Off Selectivity 60 dBc
Bluetooth
Supported Pro󳝌le
HFP 1.7/A2DP 1.3/AVRCP 1.6/
PBAP 1.2/MAP 1.2/SPP 1.2/
BIP 1.2
Supported Bluetooth
Speci󳝌cation
4.2
Frequency Range/
Output Power
2402 ~ 2480 Mhz
Max. 4.0 dBm
Number of Channels 79
Specication
Speci󳝌cation

Genesis GV80 Specifications

General

Brand	Genesis
Model	GV80
Category	Automobile
Language	English
