Genesis SHERLOCK 102 User Manual

44-00-0297 SHERLOCK102/202 REV. 4.1 05-02-1548
ITEM PART#
Sherlock 102 Control (SHER102) 82-0339
Sherlock 102 Control NEMA 4X (SHER102-4) 60-0141
Sherlock 102 Control With Analog Output (SHER102-A) 82-0375
Sherlock 202 Control (SHER202) 82-0319
Sherlock 202 Control With Zone Isolation (SHER202-R) 82-0344
Sherlock 202 Control With Analog Output (SHER202-A) 82-0380
Sherlock 202 Control NEMA 4X (SHER202-4) 60-0133
Optional Strobe Light Factory Mounted on Control (-S) 87-0085
Solid State CMOS CFC/HCFC Sensor 82-0100
Solid State CMOS CFC/HCFC Sensor NEMA 3R 60-0113
Solid State CMOS HFC Sensor 82-0101
Solid State CMOS HFC Sensor NEMA 3R 60-0128
Solid State CMOS Ammonia (NH
3
) Sensor 82-0102
Solid State CMOS Ammonia (NH
3
) Sensor NEMA 3R 60-0129
Solid State CMOS CFC/HCFC Ventline Sensor 60-0018
Solid State CMOS HFC Ventline Sensor 60-0028
Solid State CMOS Ammonia (NH
3
) Ventline Sensor 60-0027
Solid State High Pressure Ventline Sensor 60-0076
Electrochemical Oxygen Deprivation Sensor 82-0108
Electrochemical Ammonia (NH3) Sensor 82-0460
Electrochemical Ammonia (NH3) Sensor, Low temp 82-0461
R-11 Infrared Sensor NEMA 3R 45F to 120F 60-0057
R-12 Infrared Sensor NEMA 3R 45F to 120F 60-0104
R-22 Infrared Sensor NEMA 3R 45F to 120F 60-0053
R-114 Infrared Sensor NEMA 3R 45F to 120F 82-0260
R-123 Infrared Sensor NEMA 3R 45F to 120F 60-0137
R-134a Infrared Sensor NEMA 3R 45F to 120F 60-0054
R-402a Infrared Sensor NEMA 3R 45F to 120F 82-0249
R-404a Infrared Sensor NEMA 3R 45F to 120F 60-0052
R-408a Infrared Sensor NEMA 3R 45F to 120F 60-0065
R-409a Infrared Sensor NEMA 3R 45F to 120F 60-0066
R-410a Infrared Sensor NEMA 3R 45F to 120F 60-0165
R-500 Infrared Sensor NEMA 3R 45F to 120F 82-0288
R-502 Infrared Sensor NEMA 3R 45F to 120F 60-0059
R-507a Infrared Sensor NEMA 3R 45F to 120F 60-0061
R-717(NH
3
) Infrared Sensor NEMA 3R 45F to 120F 60-0095
R-11 Infrared Sensor NEMA 3R -30F to 45F 60-0058
R-22 Infrared Sensor NEMA 3R -30F to 45F 60-0047
R-404a Infrared Sensor NEMA 3R -30F to 45F 60-0051
R-408a Infrared Sensor NEMA 3R -30F to 120F 60-0065
R-502 Infrared Sensor NEMA 3R -30F to 45F 60-0060
R-507a Infrared Sensor NEMA 3R -30F to 45F 60-0062
R-717 (NH3) Infrared Sensor NEMA 3R -30Fto 45F 60-0096
Gas Canister, 250 ppm R22, Air Balance, 34L 46-0004
Gas Canister, 1000 ppm R22, Air Balance, 34L 46-0024
Gas Canister, 250 ppm R22, Air Balance, 104L 46-0029
Gas Canister, 250 ppm R134a, Air Balance, 34L 46-0005
Gas Canister, 250 ppm R123, Air Balance, 34L 46-0006
Gas Canister, 50 ppm R123, Air Balance,34L 46-0030
Gas Canister, 250 ppm R-404A, Air Balance, 34L 46-0022
Gas Canister, 250 ppm R-507A, Air Balance, 34L 46-0031
Gas Canister, 250 ppm R11, Air Balance, 34L 46-0011
Gas Canister, 250 ppm R12, Air Balance, 34L 46-0023
Gas Canister, 17% Oxygen, Nitrogen Balance, 34L 46-0007
Gas Canister, 20.9% Oxygen, Nitrogen Balance, 34L 46-0008
Gas Canister, 20.9% Oxygen, Nitrogen Balance, 104L 46-0013
Gas Canister, 50 ppm Ammonia, Air Balance, 75L 46-0027
Gas Canister, 250 ppm Ammonia, Air Balance, 75L 46-0026
Gas Canister, 500 ppm Ammonia, Air Balance, 75L 46-0009
ITEM PART#
Regulating Valve, Standard Calibration Kit 46-0003
Regulating Valve, Ammonia Calibration Kit 46-0010
Calibration Kit For R-11 Sensors 88-0221
Calibration Kit For R-12 Sensors 88-0286
Calibration Kit For R-22 Sensors 88-0152
Calibration Kit For R-134A Sensors 88-0153
Calibration Kit For R-123 Sensors 88-0154
Calibration Kit For R-404a Sensors 88-0215
Calibration Kit For R-507a Sensors 88-0396
Calibration Kit For Oxygen Deprivation Sensors 88-0155
Calibration Kit For R-717 (NH3) Sensors 88-0156
Remote Alarm: 82-0127
Auto Alarm Dialer Model 1104: 87-0001
Auto Alarm Dialer Model 1108: 87-0008
Remote Alarm And Strobe: 88-0109
Horn 87-0030
Horn/Strobe 87-0005
1 Horn/Strobe w/Power Kit: 88-0227
2 Horn/Strobes w/Power Kit: 88-0228
3 Horn/Strobes w/Power Kit: 88-0229
1 Horn/Strobe w/Power Kit: 88-0230
2 Horn/Strobes w/Power Kit: 88-0231
3 Horn/Strobes w/Power Kit: 88-0232
1 Horn/Strobe: 88-0233
Strobe Light w/Power Kit: 88-0234
2 Stacked Beacons with Horn (Red, Amber) 88-0292
3 Stacked Beacons with Horn (Red, Amber, Blue) 88-0252
Break Glass Pull Station w/Back Box (Blue) 88-0268
Break Glass Pull Station w/Back Box (Yellow) 88-0271
GenCom Communications Installation Manual 44-0025
Gencom Interface Board to Modem 80-0010
Gencom Interface Wire Harness 80-0145
Gencom to Modem Ribbon Cable – 8” 80-0202
“The Stick” FAX Phone Switch 87-0002
GenCom Communication: 88-0190
GenCom Communication (w/ 33.6 KB Modem) 88-0191
Inline Filter 30-0026
Transformer, Wall Plug, 12V DC 250ma 33-0008
Transformer, Wall Plug, 12V DC 250ma 33-0032
Transformer, Wall Plug, 12V DC 1.5a 33-0051
Fuse, 3.15 Amp, Time Lag 33-0054
Fuse, 6.3 Amp 33-0038
Sherlock 102 Control Power Supply 24 VAC 33-0025
Power Supply, Switching, 12V DC 3a 33-0068
Power Supply, Switching, 12V DC 6.2a 33-0072
Housing, Horn Strobe Power Supply w/ Knockouts 35-0075
Belden #8443 Triad Twisted Sensor Cable 22 AWG 27-0063
Belden #8770 Triad Twisted Shielded Sensor Cable 18 AWG 27-0094
Belden #9364 Triad Twisted Shielded Sensor Cable 20 AWG 27-0082
Testing Fluid, Sherlock CFC/HCFC and HFC Sensors 45-0008
Testing Fluid, Sherlock Ammonia Sensors 45-0019
Manual Sherlock 2 SERIES (Obsolete) 44-0093
Manual Sherlock 102/202 (SHER102 / SHER202) 44-0297
Manual Solid State CMOS Refrigerant Gas Sensor 44-0283
Manual Infrared Refrigerant Gas Sensor (Obsolete) 44-0221
Manual Infrared Refrigerant Gas Sensor 44-0295
