Genie GS-1330m User Manual

Operator's Manual First Edition • Second Printing
Legend
22 GS
™
-1330m Part No. 1290846GT
Legend
1 Platform guard rails
2 Lanyard anchorage points
3 Platform controls
4 Manual storage container
5 Platform extension
6 Flashing light
7 Transport tie-down
8 Steer tire
9 Pothole guard
10 Ground controls
11 LCD readout
12 Non-steer tire
13 Inverter (optional)
14 Brake release switch (hydraulic side)
15 Emergency lowering knob
16 Entry ladder / transport tie-down
17 Battery charger (on battery side of machine)
18 Tilt alarm
19 Safety arm
20 Air line to platform (optional)
21 Platform extension release pedal
22 GFCI outlet
23 Platform entry gate
24 Foot switch (if equipped)
1
5
9
2
3
12
19
18
6
17
16
15
7
7
11
10
7
8
13
14
6
23
22
21
24
20
4
