First Edition • Second Printing Operator's Manual
Specifications
Part No. 1290846GT GS
™
-1330m 59
Specificati ons
Model
GS-1330m
Height, working maximum 18 ft 10 in 5.9 m
Height, platform maximum 12 ft 10 in 3.9 m
Height, stowed maximum fixed
rail
80 in 202 cm
Height, stowed maximum,
rails up
80 in 202 cm
Height, stowed maximum,
rails folded
66 in 168 cm
Platform height, stowed
maximum
35.2 in 90 cm
Height, guard rails 43 in 110 cm
Width 30.5 in 78 cm
Length, stowed 56 in 141 cm
Length, platform extended 74 in 187 cm
Platform extension length 18 in 46 cm
Platform dimensions (length x
width)
50 x 27 in 126 x 67 cm
Maximum load capacity 500 lbs 227 kg
Wheelbase 39 in 98 cm
Turning radius (outside) 61 in 155 cm
Turning radius (inside) 15.7 in 40 cm
Ground clearance 2.4 in 6 cm
Ground clearance
Pothole guards deployed
0.63 in 2 cm
Weight 1950 lbs 885 kg
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Power source
2 Batteries, 12V 85AH
System voltage
24V
AC outlet in platform Standard
Maximum hydraulic pressure
(functions)
2250 psi 155 bar
Tire size
10 x 3 x 8 in
Total vibration value to which the hand/arm system is
subjected does not exceed 2.5 m/s
2
.
Highest root mean square value of weighted
acceleration to which the whole body is subjected does
not exceed 0.5 m/s
2
.
Operating temperature
Minimum
-20°F -29°C
Maximum
150°F 66°C
Airborne noise emissions
Sound pressure level at ground workstation <70 dBA
Sound pressure level at platform workstation <70 dBA
Maximum slope rating, stowed position
25% (14°)
Maximum side slope rating, stowed
position
25% (14°)
Note: Slope rating is subject to ground conditions with
one person in the platform and adequate traction.
Additional platform weight may reduce slope rating.
Drive speeds
Stowed, maximum
2.5 mph 4.0 km/h
Platform raised,
maximum
0.5 mph
40 ft/55 sec
0.8 km/h
12.2 m/55 sec
Floor loading information, GS-1330m
Tire load maximum 860 lbs 390 kg
Tire contact pressure 119.4 psi 8.40 kg / cm
2
824 kPa
Occupied floor pressure 237 psf 1159 kg / cm
2
11.37 kPa
Note: Floor loading information is approximate and
does not incorporate different option configurations. It
should be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
GS™-1330m Part N o. 1290846GT Operator's Manual First Edition • Second Printing
