First Edition • Second Printing Operator's Manual
Inspections
Part No. 1290846GT GS
™
-1330m 31
Test Emergency Lowering
15 Activate the up function by pressing the lift
enable button and platform up button, and
raise the platform approximately 2 ft. / 60 cm.
16 Pull the emergency lowering knob located
behind the entry ladder.
Result: The platform should lower. The
descent alarm will not sound.
Test the Tilt Sensor Operation
17 Press the ground control enter button.
Result: The ground control LCD screen will
display the tilt sensor X, Y values and the
alarm will sound. The tilt sensor is functioning
properly.
18 Turn the key switch to platform control.
At the Platform Controls
Test Emergency Stop
19 Push in the platform red Emergency Stop
button to the off position.
Result: No functions should operate.
Test the Horn
20 Pull out the red Emergency Stop button to the
on position.
21 Press the horn button.
Result: The horn should sound.
Test the Function Enable Switch and the
Up/Down Functions
22 Do not hold the function enable switch on the
control handle.
23 Slowly move the control handle in the direction
indicated by the blue arrow, then in the
direction indicated by the yellow arrow.
Result: No functions should operate.
24 Press the lift function button.
25 Wait seven seconds for the lift function to time
out.
26 Slowly move the control handle in the direction
indicated by the blue arrow, then in the
direction indicated by the yellow arrow.
Result: The lift function should not operate.
27 Press the lift function button.
28 Press and hold the function enable switch on
the control handle. Slowly move the control
handle in the direction indicated by the blue
arrow.
Machines equipped with foot switch: Press and
hold the foot switch and press and hold the
function enable switch on the control handle at the
same time.
Result: The platform should raise. The pothole
guards should deploy.
29 Release the control handle.
Result: The platform should stop raising.
