Operator's Manual First Edition • Second Printing
Operating Instructions
48 GS
™
-1330m Part No. 1290846GT
7 Connect entry swing frame with left main rail
by the pin.
Keep hands free of pinch points.
8 Carefully open the gate and exit the platform.
9 Remove the two pins from one side of the
main rails.
Keep hands free of pinch points.
10 Fold the side main rail towards the inside of
the unit.
11 Remove the other two pins from the other side
of the main rails.
Keep hands free of pinch points.
12 Fold the other side main rail towards the inside
of the unit.
Note: To assist in the removal and replacement of
the wire lock pins, pull or push back on the railing
to compress the rubber bumpers.
How to Raise the Guardrails
Follow the fold down instructions but in reverse
order, ensuring all lock pins are in place and
installed properly.
