Genius DVR-GPS300D - Page 8

!
8!
1
Video Out
7
Illumination (Night View)
13
Front camera for
outside view of the car
2
Screw
8
Light Sensor
14
AV out On/Off button
3
External antenna
jack
9
GPS Indicator
15
Buzzer
4
DC Jack (5V/3A)
10
Record Indicator
16
USB port cover
5
Cap for glare
11
Microphone
6
Back camera for
inside view of the
car
12
Hole for mounting frame
Dual Camera
USB Port of CONFIG
GPS & Record Indicator
1. Used for configuration setting and
firmware update.
1. GPS: Green/get signal,
Red/no signal
2. Record: Blue/recording
