Genius LYNX 07 - Page 33

LYNX 07 24V
ENGLISH
Guide for the installer
Page 29
Logic “E” Manual C=0 d=0 E=0
Automated
system status
Inputs
Open/Close Open Close Stop
Safety devices
y=0
Closing safety devices
y=1
Opening and closing
safety devices
Closed Opens the rod Opens the rod No effect
No effect (if active, it disa-
bles all commands)
No effect
Disables Open comman-
ds
Open Closes the rod No effect Closes the rod
No effect (if active, it disa-
bles all commands)
Disables commands Disables commands
At closure
Reverses movement to
opening
Reverses movement to
opening
No effect Stops operation
Reverses movement to
opening
Stops operation and rever-
ses on release
At opening
Reverses movement to
closure
No effect
Reverses movement to
closure
Stops operation No effect
Stops operation and resu-
mes on release
Logic “EP” Step-by-step manual C=0 d=1 E=0
Automated
system status
Inputs
Open/Close Open Close Stop
Safety devices
y=0
Closing safety devices
y=1
Opening and closing
safety devices
Closed Opens the rod Opens the rod No effect
No effect (if active, it disa-
bles all commands)
No effect
Disables Open comman-
ds
Open Closes the rod No effect Closes the rod
No effect (if active, it disa-
bles all commands)
Disables commands Disables commands
At closure
Stops operation, opens on
next pulse.
Reverses movement to
opening
No effect Stops operation
Reverses movement to
opening
Stops operation and rever-
ses on release
At opening
Stops operation, closes on
next pulse
No effect
Reverses movement to
closure
Stops operation No effect
Stops operation and resu-
mes on release
