Genius SW-HF 5.1 6000 User Manual

Service Guide SW-HF 5.1 500
Woofer
NO
DESCRIPTION UNIT NOMINAL LIMIT
1 RATED OUTPUT POWER@100Hz(10%THD) W 108
≧100
2 SENSITVITY(100Hz)@RATED O/P POWER m V 100 ±10
3 SENSITIVITY(100Hz)@1W O/P POWER m V 38 ±3.8
4 MAX INPUT LEVEL@1% THD m V 95 ±9.5
5 DISTORTION@100Hz REF O/P POWER % 0.1
≦0.5
6 FREQUENCY RESPONSE (100Hz -3DB)LOW Hz 15 ±10
7 FREQUENCY RESPONSE (100Hz -3DB)HI Hz 140 ±20
8 S/N RATIO@100Hz RATED O/P POWER d B 82
≧75
9 VR MIN NOISE (INPUT SHORTING) m V 0.1
≦0.5
10 VR MAX NOISE &HUM (INPUT SHORTING) m V 0.6
≦1.5
Version 1.0 Page 18 of 36
Chapter 2 Specifications

Genius SW-HF 5.1 6000 Specifications

General

Brand	Genius
Model	SW-HF 5.1 6000
Category	Speaker System
Language	English
