Genius SW-HF 5.1 6000 User Manual

Service Guide SW-HF 5.1 6000
Center
Ref. NO Description
Part NO.
1 Genius LOGO plate: M72 60*23*2MM EP75050198
2 cloth and cloth grill EP41010156
3 center driver unit, A-115-9, 4"Ω420W EP16040012
4 tweeter, A-52-2A, 2"8Ω10W EP16020043
5 center wood cabinet, W331.5*H160*D130MM EP53Y018J1A
6 Red/black terminal EP1A090065
7 rubber foot mat, φ18*3MM EP73060007
8 screw, 3.5*18TA EP24150024
9 paper port tube, φ22*φ25*30mm(painting black inside ) EP41590040
Rear
Ref. NO Description
Part NO.
1 Genius LOGO plate:M73 42*19*2MM EP75050199
2 cloth and cloth grill EP41010155
3 port tube EP41510054
4 tweeter, A-52-2A, 2"8Ω10W EP16020043
5 rear wood cabinet 140*H230*D130MM EP53Y019J1A
6 hanger, 34*20*1MM EP22011002
7 Red/black terminal EP1A090065
8 rubber foot mat, φ18*3MM EP73060007
9 rear driver unit, A-115-11, 4"8Ω20W EP16040014
10 screw, 3.5*18TA EP24150024
Front
Ref. NO Description
Part NO.
1 Genius LOGO plate:M73 42*19*2MM EP75050199
2 cloth and cloth grill EP41010155
3 port tube EP41510054
4 tweeter, A-52-2A, 2"8Ω 10W EP16020043
5 front wood cabinet, W140*H230*D130MM EP53Y017J1A
6 Red/black terminal EP1A090065
7 front driver unit, A-115-10, 4"8Ω20W EP16040013
8 screw, 3.5*18TA EP24150024
9 rubber feet mat, φ18*3MM EP73060007
Version 1.0 Page 24 of 36
Cha
p
ter 5 Part list
