Service Guide SW-HF 5.1 6000
Woofer
Ref. NO Description
Part NO.
1 master volume knob φ38*23 EP40758018
2 silver keystroke EP40714169A
3 LCD cover, ABS EP40810052
4 front panel EP40310321
5 transparent cover for IR receiver EP41410034
6 VR EP1B020070
7 LCD panel EP1D010029
8 SW-HF5.1 6000 CON94HB PCB, 176*84*1.6MM EP15600004
9 TDA7293 IC EP1C020033
10 SW-HF5.1 SWAMP 94V0 PCBA, 110*140*1.6MM/2 EP15500504
11 SW-HF5.1 AMP 94V0 PCBA, 180*165*1.6MM/2 EP15500505
12 BT2323 IC EP1C010004
13 TDA7265 IC EP1C010120
14 BT2258 IC EP1C010195
15 SW-HF5.1 6000INPUT94 VO PCB, 135*160*1.6MM EP15600005
16 AL sink, 284*195.5*30MM EP21100078
17 screw, 3.5*20PA EP24100079
18 fuse jack EP41610059
19 AC cable EP32020041
20 power switch EP19030008
21 SW-HF5.1 SATSP 94V0 PCBA, 118*127*1.6MM/2 EP15500503
22 SCREW, 4*25PWM EP24140018
23 transformer 230V 50HZ 28V*2-2.5A 15V*2-1.9A EP13500025
24 woofer metal mesh EP61000134
25 screw 3.5*18TA EP24150024
26 woofer driver unit, A-210-4, 8" 6ohm 100W EP16080002
27 woofer wood cabinet, W213*H393*D310MM EP536000J1
28 rubber foot mat, φ11*3MM EP73060031
29 screw, 3.5*16PA EP24100052
30 woofer foot, Φ19*16mm) EP41110034
31 screw, 3*10TA EP24170004
32 port tube B EP41510052
33 screw, 2.6*8TA EP24150005
34 port tube A EP41510051
Version 1.0 Page 23 of 36
Cha
p
ter 5 Part list
