Chapter 3. Removal and Replacement
Disassemble & Assemble the Functional cover
Step 1
Remove the two caps.
*Mark the position of the caps
Step 2
To remove 6 screws. After taking all
screws off, you can take up the
functional cover
*To install the functional cover,
reverse the steps shown above.
A
E C
F B D
