Service Manual
Disassemble & Assemble the PCBA(SUB)
Step 1
*Disassemble the functional
cover first.
To remove 4 screws.
Step 3
To remove screw.
*Mark the position of the
cables first.
To solder 4 cables. You can
take out the PCBA
*To install the PCBA,
reverse the steps shown
above.
B
C
D
A
Version 1.0
P
age 5
