Genki JK-RM21 - Spare Part Lists

３
Spare Part Lists
Below is the drawings of spare parts for the complete machine.When you open the carton, you will find
the below Parts in the carton.
Part List
Fixing tools: L-shaped wrench S5 1pc Multi-function wrench S=10,13,17,19 1pc
NO
DES.
Specification
No
s.
NO
DES.
Specification
Nos.
A1
Main Frame Set
1
53
Bolt
M12*145
2
A2
Slideway supporter
1
54
Bolt
M8*20
9
A3
Slideway
1
55
Bolt
M10*70
2
A4
Front Stabilizer
1
60
Screw
M5*12
4
A5
Pedal(L)
1
63
Standard spring washer
8
9
A6
Pedal(R)
1
64
Flat washer
8
6
A7
Seat
1
65
Locknut
M8
1
11
Pedal Axle
1
67
Combined cap nut
M10
2
22
Monitor stand
1
68
Arched washer
10
2
23
Slideway cover
1
69
Arched washer
8
4
31
Monitor
1
71
Flat washer
5
4
50
L-shaped wrench
S5
1
80
Screw
ST4.2*19
3
51
Multi-function
wrench
S=10/13/17/
19
1
