36
X, Y Synchronization Wheel Adjustment
09 Maintenance and Care
10mm open-end wrench
X-axis synchronization wheel tightness
adjustment: After aligning the eccentric wheel
with a 10mm open-end wrench, twist clockwise
and counterclockwise until the synchronization
wheel is tight and tight.
8mm open-end wrench
To adjust the tightness of the left and right
synchronization wheels of the Y-axis, use an
8mm open-end wrench to match the eccentric
wheel, and then twist clockwise and
counterclockwise until the synchronization
wheels are tight and tight.
