THE TANK
The inside of the polyethylene tank has a completely smooth surface without any sharp edges. This facilitates
the stirring of the liquid and cleaning.
THE INTAKE FILTER
The intake filter prevents the pump from drawing in impurities or residues inside the tank
THE PUMP AND THE MOTOR work with battery 12 volt or exp1osion engine (see
instuctions).
ATTENTION: normally the adjustement of the carburator is not necessary since it is already
adjusted when delivered from the factory. In the engine is not working correctly please follow
the following instructions on the adjustable “T” screw:
Turn right to optane a leaner fuel
Turn left to optain a richer fuel
THE SPRAY NOZZLE
There are two types of hand-held spray nozzles: one for spraying and one for weed control. The spray nozzle
is connected to the pump with30-bar PVC piping. The nozzle can be opened, closed, and adjusted.
OPERATING THE UNIT
CHECKS AND OPERATIONS TO BE PERFORMED BEFORE STARTING THE UNIT
1)
Start the motor switching on the button for the electric version.
As for the engine version make reference to user manual
2)
Manually open the spray nozzle C.
Proceed with caution when opening the spray nozzle. Be especially careful that there are no other
people near the unit.
3) Make sure that the fastening bolts for the surface on which the pump will be mounted are screwed
down tightly.
