Vapodest 10s
2.1. Warranty conditions
The distillation unit Vapodest 10 is manufactured following the high quality gui-
delines of EN ISO 9001:2000. On the basis of the C. Gerhardt conditions of war-
ranty our products are guaranteed for 1 year, as long as the apparatus is used in
accordance with the instructions mentioned in this manual.
Pleasenotethatthesemi-consumablepartsareexcludedfromwarranty.
2.2. Technical data
Order No.: 7610
Nominal voltage: 230 VAC - 50/60Hz
Nominal Wattage: 1600 W
Cooling water: about 3 litre per distillation minute
Cooling water pressure: > 0,5 bar
Pump capacity:
-Diaphragm pump H
2
O 11 - ca. 30 ml/min with water
-Diaphragm pump Reagent 0 - ca. 170 ml/min with NaOH
Store tank: any size, recommended: KAN 20
 Dimensions: 440x690x340mm(WxHxD)
Weight: 25 kg
Amount of distillate: see table
Steam capacity Steam capacity
Level 10 (100 %) Level 1 (70 %)
Dest.-time = 2 min ca. 25 ml ca. 15 ml
Dest.-time = 4 min ca. 60 ml ca. 40 ml
Dest.-time = 6 min ca. 110 ml ca. 60 ml
Dest.-time = 10 min ca. 190 ml ca. 110 ml
2.3. Operating conditions
Vapodest distillation systems can be run under normal laboratory conditions.
Fortheconnectiontothetap(coldwater)axedconnectionwith1/2inchthread
is needed.
