Gerhardt Vapodest 45s - Spare parts

45
Vapodest 45s
11 Maintenance
11.2.1. Description of the tubing diagram
Pos. Description Item-No.
1 Diaphragm pump NaOH 1001738
2 Diaphragm pump H
3
BO
3 ,
1001736
3 Diaphragm pump H
2
Ofor steam generator 1001736
4 Diaphragm pump H
2
O for sample 1001736
5 Peristaltic pump for suction sample 1000084
6 Peristaltic pump for suction receiver 1000084
7 Pinch-solenoid valve, steam 1000090
8 Magnetic valve with pressure control 1000363
9 Pinch-solenoid valve, shut-off 1000090
10 Verprene-tubing 4 x 8 mm 1000498
11 Verprene-tubing 4 x 8 mm 1000498
12 Non-return valve for diaphragm pumps 1000081
13 Tubing reduction PP 51 x 10 x 5 mm 1000398
14 Silicone tubing 4 x 7 mm 1000488
15 Silicone tubing 4 x 7 mm 1000488
16 Verprene-tubing 8 x 12 mm 1000499
17 Verprene-tubing 4 x 8 mm 1000498
18 Silicone tubing 4 x 7 mm 1000488
19 Silicone tubing 4 x 7 mm 1000488
20 Ventilation glass 1000048
21 Novoprene-tubing 4,8 x 8 mm 1002289
22 Tubing reduction 1000397
23 Silicone tubing 6 x 10 mm 1000484
24 PP-distributor with PP-thread 1000538
25 NKT-valve (built in with brass tting) 1002842
26 Silicone tubing 8 x 16 x 80 mm 1000497
27 Steam generator 1000232
28 PTFE-inlet tubing NaOH 1003401
29 Silicone tubing 8 x 16 for cooling water inlet 1000497
30 Silicone tubing 8 x 16 for cooling water outlet 1000497
31 Vitone-tubing 6 x 12 * 50 mm 1000495
32 Silicone tubing 4 x 7 mm 1000488
When you order additional tubing, please make sure to also give the desired
length!
