Informationmode
Historyofbreakdownsandoperationconditions
Errorreports
Informationmodecanbeactivatedbypressingthebutton_________.Byrepeatedpressing
itispossibletoscantheseindexes:
Index
1Currentintensityoftheflame
2Currenttemperatureofoutletheatingwater
3Currenttemperatureofreturningheatingwater
4Currenttemperatureofhotwater
5Pressureintheheatingsystem
6Applicationtype
7Currenttemperatureofwastegas
8Currentflowrateexpressedbythefrequencyofthesensor(Hz)
9Currentcalculatedvalueofoutletheatingwaterbytheoutsidetemperature(inthe
modeofequithermalregulation)
10Currentvalueofoutsidetemperature
Theinformationmodecanbefinishedbypressingthebutton_________.Themodeis
automaticlyfinishedifin1minutenochangeisdone.
Bykeepingthebutton_________forthetimelongerthan3minutesthehistoryofboiler
breakdownsisactivated.OnthedisplaythereissymbolEwithrelevanterrorcode(see
chartoferrorreports).Searchinginthelistofbreakdownsismadebythebutton
_________andserialnumberoftheerrorandsymbolEaredisplayedalternately.
Thismodecanbestoppedbypressingthebutton________again.Thehistoryof
breakdownsendsautomaticlyafter30secondssincelastchange.
IncaseofanyerroronthedisplayappearsthesymbolEwithrelevanterrorindex.
Chartoferrorreports:
Index
01Flameblockingaftersomeunsuccessfulattempts
02Falseflamesignal
03Safetythermostatopen
05Errorincommunicationbetweencontrolelectronicsandventilator
07Hightemperatureofwastegas,TTBsensor
-----
08Errorintheflamecircuit
09Errorinthegasvalvecircuit
10ErrorinthecommunicationwiththememoryofEEPROMcontrolelectronics
11emperatureofreturnheatingwaterishigherthantemperatureofoutletheating
water
21ADCHuperror(InternalerrorofCVBCelectronics)
