Settingupsummermode
Thewaysofregulationoftheboiler
Operationoftheboilerwiththethrough-flowheatingofwater(KST).
Operationoftheboilerwiththeexternalhotwaterstoragetank
Summermodeissetupbythebutton___________.Theoperationoftheboilerinthe
summermodeisdisplayedbytheloghtofLEDdiodeoverthebutton_______.Theboilerin
summermodeignoresanyrequestforheatingfromtheroomthermostatorOPENTHERM
contacts.
Theboilerinsummermodecanonlypreparehotwater.Summermodeoftheboilerisalsoa
standbymodeforactivatinganti-freezingfunctionandprotectionofthepump.
Anti-freezingfunctionprotectstheboileraswellastheheatingcircuit.Ifthetemperatureof
heatingwaterdropsunder6°C,theboilerstartsworkingtominimumheatingoutputandturns
offafterhavingreached15°Ctemperatureofheatingwater.
Automaticprotectionofthepumppreventsblockingthepump,soifitisnotworkingmore
than24hours,thepumpisactivatedfor30seconds.
1.Operationwithoutaroomthermostatinthiscaseitisnecessarytohaveaconnectionon
theterminalboardbetweenT1andT2contacts.Thisconnectionismadefromtheproduction
unit.Theboilerpreparesheatingwatertothechosentemperature.
2.Operationwitharoomthermostattheboilerisregulatedbytheroomthermostatandkeeps
thesetuptemperatureofheatingwater.TheroomthermostatisconnectedtotheT1andT2
contactsontheterminalboardinsteadofadisconnectedjumper.Or,insteadoftheroom
thermostat,aregulatorsuchasHONEYWELLCX51,CR11010whichapartfromother
functionsalsoservesasaroomthermostat,canbeconnectedthroughOPENTHERM
contacts.
.Operationoftheboilerbytheoutsidetemperature.Theboilerhasanoutsidesensorof
temperature(HoneywellSO10075)andanequithermalcurveischosen.Totheboilercanbe
alsoconnectedaroomthermostatwhichinfluencesswitchingonandoffoftheboilerandthe
temperatureofheatingwaterissetautomaticlybytherealoutsidetemperature.
Fortheoperationoftheboilerwithathrough-flowheatingofwater(KST),thedemandfor
heatingisrecordedbythethrough-flowsensorofhotwaterrespondingtohotwater
withdrawal.Themaximumconnectingpressureofhotwatercanbeof6bar.Intheareas
withhigherhardnessofwateritisnecessarytosoftenthewaterenteringtheboilertoprevent
incrustationoftheboardheatexchangerforhotwater.
FortheoperationwiththeexternalhotwaterstoragetankitisnecessarytoconnecttotheL,
N,Rcontactsontheterminalboardthedriveofathree-wayvalvewithoutamicroswitchand
totheS1,S2contactsasensorforhotwatertemperature.Theboilerprepareshotwaterin
winteraswellasinsummermodewhilehotwaterisaprioritytotherequestforheating.If
theboi
Ù
Note:ThecontactroomthermostatcannotbeusedontheOPENTHERMcontacts.Theseare
forconnectingtheregulatorthatiscompatibleincommunicationwithOPENTHERM.
3
Incaseofincrustationoftheboardheatexchangercausedbyoperationonhardwater
thereisnoguarantee.
lerworkswithouthotwaterpreparation,theS1andS2contactsareconnectedwitha
connectionequippedwitha2,2kresistor.
Accessoriesforconnectionoftheexternalhotwaterstoragetank:
1.Three-wayvalveHoneywell1“+VC6013MP6000drive
orthealternationthree.wayFUGAS ľ“valve+drive(codeRZ18+RZ19)
2.HoneywellSO10045hotwatersensorusedforthesleevewith1mcable.
