German pool PAC-CH416-SC - Product Structure

P.8
Product Structure
1
6
7
2
3
4
5
9
8
10
11
12
13
14
15
16
17
10. Condensation Drain Port
11. Drainage Hose
12. Remote Control
13. Exhaust Hose Connector
14. Exhaust Hose
15. Exhaust Hose Adaptor
16. Window Adaptor Kit
17. Window Adaptor Buttery Nut
18. Window Unit Kit & Cover
11
18
1. Control Panel
2. Air Outlet & Louvre
3. LED Display
4. Casters
5. Handle
6. Air Inlet & Filter
7. Exhaust Hose Fastener
8. Continuous Drainage Outlet
9. Air Inlet
