Setting Up the Machine on a Network
26
3
*1
Appears when the IEEE 1394 interface board (optional) is installed.
*2
Appears when the IEEE 802.11b (wireless LAN) board (optional) is installed.
If Ethernet and IEEE 802.11b (wireless LAN) are both connected to the machine, the
selected interface has priority.
*3
Check [Effective] is selected for TCP/IP.
IEEE 802.11b (wire-
less LAN)
Interface Set-
tings/Network
See p.34 “Interface
Settings/Network”.
IP Address $
Gateway Address $
DNS Configuration ❍
WINS Configuration ❍
LAN Type
*2
$
Ethernet Speed ❍
Effective Protocol
*3
$
Host Name ❍
Domain Name ❍
Interface Set-
tings/IEEE 802.11b
*2
See p.37 “Interface
Settings/IEEE
802.11b”.
Communication Mode $
SSID Setting ❍
Channel ❍
WEP (Encryption) Setting ❍
Transmission Speed ❍
File Transfer
See p.38 “File Trans-
fer”.
Default User Name/ Password
(Send)
❍
Scanner Recall Interval Time ❍
Number of Scanner Recalls ❍
Interface Settings
To Next Page
