BA 46/47 and BAE 46/47, socket-weld end
DN
1
[mm]
15
20
25
32
40
50
[in]
½
¾
1
1¼
1½
2
D (BAE only)
[mm]
154
H1
[mm]
126
126
126
126
132
132
H2 (BA)
[mm]
172
172
172
172
213
213
H3 (BAE)
[mm]
385
385
385
385
425
425
L
[mm]
200
200
200
200
250
250
S1
[mm]
20
S2 (BA)
[mm]
180
S3 (BAE)
100
Weight (BA)
[kg]
3.7
3.9
4.2
5.1
8.3
9.5
Weight (BAE)
7.8
8.0
8.3
9.2
12.4
13.6
1
BA 47 and BAE 47 in DN 25, 40, 50 only
