Qualification of personnel
Specialist personnel must have knowledge and
experience of the following areas:
explosion and fire precautions and occupational
health & safety provisions applicable at the site
of installation
work on pressure equipment
producing pipe connections
working with hot or pressurised fluids
lifting and transporting loads
all information in this installation & operating
manual and other applicable documentation
connecting the power supply of the actuator
Typographic features of warning
notes
Notes with the heading DANGER
warn
against imminent dangerous situations that
can lead to death or serious injuries.
es with the heading WARNING warn
against possibly dangerous situations that
could lead to death or serious injuries.
Notes with the heading CAUTION warn
against dangerous situations that could
lead to minor or moderate injuries.
Formatting features for warnings
of property damage
This information warns of a situation
leading to property damage.
Description
Scope of supply and equipment
specification
Scope of supply
For equipment types BA 46 and BA 47, delivery
includes the following:
one continuous blowdown valve
one sampling valve
one sealing ring A17 × 23 × 1.5 mm
this installation & operating manual
For equipment types BAE 46 and BAE 47, delivery
includes the following:
one blowdown valve with actuator
one sampling valve
one sealing ring A17 × 23 × 1.5 mm
this installation & operating manual
actuator installation & operating manual
Manufacturer's Declaration for the actuator
The equipment is packaged ready for installation
with sampling valve supplied.
Equipment specification
BA and BAE models have different types of
actua
tor. Below, the two types of actuator
are shown in separate diagrams. The body
with inner parts is identical in both valves
and is shown separately.
