GESTRA BA 46 - Page 44

44
Pressure and temperature ratings of BA 47 and BAE 47
Type of connection
PN 63 flange, socket-weld ends and butt-weld ends
Pressure
1
p [bar]
63.0
58.5
52.5
43.5
Temperature
1
T [°C]
20
100
200
300
1
Operating limits for strength of body/cover to EN 1092-1
Operating data: Maximum pressure 46.7 [bar] at boiling temperature 261 [°C]
Type of connection
CLASS 600 flange, socket-weld ends and butt-weld ends
Pressure
1
p [bar]
102.1
93.2
87.6
79.6
Temperature
1
T [°C]
20
100
200
300
1
Operating limits for strength of body/cover to ASME B16.5
Operating data: Maximum pressure 55 [bar] at boiling temperature 271 [°C]
