GESTRA BA 46 - Page 9

9
With electric actuator, BAE
No.
Designation
4
Rating plate
10
Actuator
11
Bracket
12
Coupling
No.
Designation
13
Control pin
14
Thrust ring
15
Spring
The following actuators are available as standard:
 EF 10
 EF 10-1
 EF 0.7
 EF 0.7-1
Other actuators are available on request.
In these models, the opening signal can be sent by
various controllers. The actuator and control system
are described in their own separate installation &
operating manuals.
