11
• Check that all terminal screws are tight..
• If the building where the equipment is installed has a separate
equipotential bonding system, a wire must be run from this to the
earthing (grounding) terminal of the surge protection. The surge
protection is located in the terminal box. See the wiring diagram.
• If the control system of the equipment is to be connected to a
standalone computer, the power supply to the computer should be
taken from the the same distribution board as the equipment is
connected to. Common supply is important in order to avoid
potential differences and therefore the risk of damage to the
electronic circuits of the equipment.
• A printer used to print from the equipment must be
connected in accordance with the wiring diagram. Normally
it will take its supply directly from the electrical system of
the equipment. Some equipment has sockets for a printer. If
so, these are marked with the symbol for heavy current and
the text E110 and 230 V. The signal cable is connected to a
multipole socket marked E110.
• A printer used elsewhere must be powered from the same
distribution board as the equipment. Common supply is important in
order to avoid potential differences and therefore the risk of damage
to the electronic circuits of the equipment.
• The supply cable to the sterilizer should be run so that the
temperature rise in the cable due to its insulation and ambient
temperature remains within permissible limits.
• The routing and overcurrent protection of the supply cable must be
such that the sterilizer cannot be subjected to short-circuit currents
exceeding 6 kA.
• The following requirement is applicable in countries there IEC
61000-3-3 applies: Equipment with a current less than 16 Amps on
each phase which is supplied from a public power distribution
system applies to the directive. The public power distribution system
General:Connect the equipment through a nearby multi-
pole lockable, safety-marked switch to a three-phase
supply with non-disconnectible protective earth
conductor.
In the planning phase: Concerning voltage and frequency,
mains cicuit breaker ratings and wiring sizes, see the
document “Technical data”.
When connecting the equipment: connect as shown on the
wiring diagram. The drawing number is given in the
documentation of the equipment.
