113
Foreign particles in the valves may block the valve in the open
position and cause leaky operation, so that open doors close or media
valves accidentally open, for example.
After working on the control valves, always check that the doors do not
close when closing is not activated. The compressed air must be turned
on for this check.
Pt 100 sensor (RTD)
Metallic enclosure: Acid-proof stainless steel (AISA 316 or similar)
Temperature range: 0 to +140 °C
Working pressure: -1 to +3 bar
Standard: IEC 751-1983, Class A, four-wire.
Observe extreme cleanliness when working on control
valves. Be aware of the risk of foreign particles in the
valves, which may cause unintended operation. After
working on the control valves, check that the doors do not
close when they are not meant to.
Model
Cable
Type Diagra
m
Metallic enclosure
Material Length Length Diamete
r
Type
470 11 44 - 01 Silicone rubber 8 m Single Fig 1 150 mm 3 mm Bent
470 11 44 - 02 Silicone rubber 8 m Single Fig 1 150 mm 3 mm Straight
470 80 21 - 01 PVC 3 m Single Fig 1 120 mm 2.5 mm Bent
470 80 21 - 02 PVC 5 m Single Fig 1 350 mm 3 mm Bent
470 80 21 - 03 PVC 5 m Single Fig 1 260 mm 3 mm Bent
470 80 21 - 04 PVC 8 m Single Fig 1 120 mm 3 mm Bent
570 03 09-02 PVC 8 m Single Fig 1 120 mm 3 mm Bent
570 03 08-01 Silicone rubber 8 m Double Fig 2 150 mm 3 mm Bent
570 00 15 - 01 Silicone rubber 8 m Double Fig 2 150 mm 3 mm Bent
570 00 15 - 02 PVC 2 x 5 m Double Fig 1 120 mm 3 mm Straight
570 00 15 - 03 Silicone rubber 8 m Double Fig 2 150 mm 3 mm Bent
570 00 15 - 04 PVC 2 x 5 m Double Fig 1 150 mm 3 mm Bent
570 06 93-01 Silicone rubber 3 m Double Fig 2 195 mm 4,5 mm Bent
570 06 93-02 Silicone rubber 3 m Double Fig 2 260 mm 4,5 mm Bent
