Geyser Classic - Page 6

6
1
5
6
3
4
8
10
2
7
11
9
12
12
Grommet
CONNECTION DIAGRAM
1
Cover (monoblock)
2
Housings with cartridges
3
Triple adapter with a tap
4
Connection pipe 1/4”
5
Insert to x a cartridge
7
Tap
8
Decorative bowl
9
Rubber gasket
10
Plastic washery kit
11
Fastening nut with a washery kit
6
Collet clamp screw 1/4’’ JG
System is connected to cold
water pipe
