About this document
1 About this document
These instructions describe the installation and commissioning of the GEZE Boxer E-guide rail.
In conjunction with:
à Geze Boxer size 2-4
à Geze Boxer size 3-6
Opening angle of doors: approx. 120°.
1.1 Product description
This guide rail is approved for installation on single leaf re and smoke protection doors. The system includes
an electrical hold-open device for the door leaf. In case of power interruption, the electrical hold-open device is
triggered and the door closes automatically.
1.2 Related documents
Additional documents for the installation and connection of the system are supplied with every component.
Please follow these instructions.
For mounting of the door closer, refer to the Boxer mounting instructions.
2 Key to symbols
Warning
In these instructions, warnings are used to warn against material damage and injuries.
X
Always read and observe these warnings.
X
Follow all instructions marked with the warning symbol and the word WARNING.
Warning
symbol
Warning Meaning
DANGER
Danger for people.
Non-observance can result in death or serious injuries.
–
CAUTION
Information to prevent damage to property and to understand and optimise workow.
Further symbols used in these instructions
Important information and technical notes are emphasised to illustrate the correct operation.
Symbol Meaning
means “Important note“
means “Additional information”
X
Symbol for a user action. Here you have to take an action.
X
Observe the sequence if there are several action steps.
3 Product liability
According to the denition of manufacturer‘s liability for his products in the Product Liability Act, the informati-
on contained in this brochure are to be followed. Ignoring this information absolves the manufacturer from his
liability.
4 Safety instructions
à Installation, commissioning and repairs must be performed by a specialist.
à Use only GEZE original parts for repair work.
à Unauthorised modications of the system excludes GEZE from the liability for any resulting damage.
à When used in re and smoke barriers, all local regulations should be observed.
à Please observe the document “Instructions for Installation, Commissioning, Operation and Maintenance of the
GEZE Hold-Open Device FA GC“.
à Restrict the opening angle of the doors by a door stopper.
GB 2
