GEZE ECturn Inside Wiring Diagram

ECturn/ECturn Inside
40
Parameter menu
DPS Service LEDs Parameter Encoding Explanation
5 4 3 2 1
Oe
**
● ● ● ●
Error list see error list Query of the last 10 errors
pT
***
○ ○ ● ●
Start production test Start production test (no setting possibility)
le
***
○ ○ ● ○
Starting/terminating teaching L1
○ ○ ○ ○ ●
Drive is learning
○ LED o
● LED on
* LED5 ashes with 1 Hz
** LED5 ashes twice with 1 Hz
*** LED5 ashes three times with 1 Hz
bold Factory setting
21.1 Value table for service LEDs and display programme switch
DPS Service LEDs
5 4 3 2 1
0
○ ○ ○ ○ ○
1
○ ○ ○ ○ ●
2
○ ○ ○ ● ○
3
○ ○ ○ ● ●
4
○ ○ ● ○ ○
5
○ ○ ● ○ ●
6
○ ○ ● ● ○
7
○ ○ ● ● ●
8
○ ● ○ ○ ○
9
○ ● ○ ○ ●
10
○ ● ○ ● ○
12
○ ● ○ ● ●
14
○ ● ● ○ ○
16
○ ● ● ○ ●
18
○ ● ● ● ○
20
○ ● ● ● ●
25
● ○ ○ ○ ○
30
● ○ ○ ○ ●
35
● ○ ○ ● ○
40
● ○ ○ ● ●
45
● ○ ● ○ ○
50
● ○ ● ○ ●
55
● ○ ● ● ○
60
● ○ ● ● ●
65
● ● ○ ○ ○
70
● ● ○ ○ ●
75
● ● ○ ● ○
80
● ● ○ ● ●
85
● ● ● ○ ○
90
● ● ● ○ ●
