GEZE GC 304 R User Manual

13
InstallationGC 304 R
4.4 Cabling
X
Note the wiring diagrams for the drives.
Upon activation, the output of the GC 304 R is closed (24V applied to the KI
input).
X
Set the type of contact for KI and KA to “normally opened contact”.
WH
YE
BN
GN
80 mA
-UB
+UB
GC 304 R
1
2
3
4
5
24V
KI
GND
2
21
1
KI
24V
KA
GND
4
23
1
KA
