Installation GC 339
16
4.5 Cabling
X
Heed wiring diagrams for the sliding door drives.
1
GC339
GND
1
4
24Vsw
11
SIS1
1
GND
4
24Vsw
10
TST
SIS1
1
GND
4
24Vsw
1
GND
4
24Vsw
10
TST
12
SIS2
Or
110 mA
GC 339
COM
+
BN
GN
GY
PK
BU
RD
WH
YE
SIS2
1
2
1 AIR curtain
2 Test
When activated, the output of the GC 339 is opened (GND applied to the
SIO input).
X
Set the type of contact for SIO 1 and SIS 2 to “normally closed contact”.
X
Test the sensor with GND.
For compliance with EN16005 and DIN18650, the test output of the door
control must be wired and the sensor tested.
