Introduction
1 Introduction
1.1 Symbols and illustrations
Warning notices
In these instructions, warning notices are used to warn against material damage and injuries.
X
Always read and observe these warning notices.
X
Observe all measures marked with the warning symbol and warning word.
Warning
symbol
Warning
word
Meaning
CAUTION
Danger to persons.
Non-compliance can result in minor injuries.
More symbols and illustrations
Important information and technical notes are highlighted to explain correct operation.
Symbol Meaning
means “important note”;
Information on avoiding material damage, improved understanding or optimising the workows
means “additional Information”;
The user's attention should be drawn to important addition information. There is no danger to persons
or property, but it is particularly useful to read the additional information carefully
X
Symbol for an action: This means you have to do something.
X
If there are several actions to be taken, keep to the given order.
1.2 Product liability
In compliance with the liability of the manufacturer for his products as dened in the German “Product Liability Act”,
compliance with the information contained in this brochure (product information and intended use, misuse, product
performance, product maintenance, obligations to provide information and instructions) must be ensured. Failure
to comply releases the manufacturer from his statutory liability.
1.3 Special cases
In certain cases, such as with
à Special wiring
à special function settings (parameters)
à Special software
dierences from the information given in this user manual may occur.
X
If this is the case, please ask the service technician responsible.
1.4 More detailed information
Information about commissioning and service can be found on the following diagrams:
à Wiring diagram Slimdrive EMD
à Installation instructions Slimdrive EMD
