Integrierte Schließfolgeregelung Slimdrive SD Türblattmontage Bandseite , Datei 88340 SD_IS-T-BS_180400.p65
Allocation and position of construction elements
Passive leaf Slimdrive SD
(example)
Active leaf Slimdrive SD-IS
Active leaf DIN right ( TS 5000 with Slimdrive SD-IS )
Active leaf DIN left ( Slimdrive SD-IS with Slimdrive SD )
long rail
short rail
Active leaf
Slimdrive SD-IS
Passive leaf TS 5000
(example)
long rail
short rail
