4.Theendofthefusionoperationsisindicatedby

 asignaltoneandlightingoftheEndsignallamp

 followingexpirationofthelongestfusiontime.

The Readylampextinguisheswhenthetimes

 expireinthechannelswithshorterfusiontimes.

5.Disconnectfusioncablefromfitting,only Mains

 lamplights,allthreefusionchannelsare

 released.

Maintenance:

Cleantheunitwithadampcloth.Cleanthe

case,thefrontpanelandplateswithalcoholor

methylatedspiritsonly;donotusethinnersor

solvents.

Technical data

Voltage: U

Prim 230V

USek 185V

Frequency:  50/60Hz

Current: IPrim 7,5A

ISek 3x2,5A

Output: PPrim 25–1400W

UnitNo.

3.StartfusionprocesswithStartbutton,Fusion

 lampflash,startoffusionisadditionallyindicated

 acousticallybyasignaltone.

The

Readylamplightsforthefusionchannel

connected.

Everyfusionchannelconnectedrecognizesthe

fittingconnectedanditsdimensions

independently.

Uptothreefusionoperationscanbeperformed

simultaneously,evenindifferentdimensions.

Fusionchannelsnotconnectedareblocked

(withoutpower)duringthefusionprocess.

2.Connectfusioncabletotherelevantfittingor

 fittings,Readylamplights.

Functional description

1.Connecttheunittothemains;allpilotlamps

 lightupfortwoseconds.TheMainsindicator

 thenremainslitcontinuously.

GF INSTAFLEX HWSG 3 User Manual
