10
Attach the drive unit.
BAGAE01103_Z002
Note – possible stalling of the gearbox!
Do not hit the gearbox with a hammer when placing the drive unit on the shaft.
Hammer blows or similar impacts of force may stall the gearbox.
Tighten all connection elements on the drive
(M8) to 25 Nm. Install all other connection
elements according to the specifications of
the door manufacturer.
