6
2 Technical data
Designation
Unit
Output speed 24 rpm
Output torque 50 (50)
1)
Nm
Output / hollow shaft 25,40 mm
Series KG 50 -
Limit switch range
(maximum revolutions of the output / hollow shaft)
20 -
Supply voltage 1N~ 230 V
Operating current 3,50 A
Operating frequency 50 Hz
Power factor cos φ 0,99 -
Safety circuit 24 V
Degree of protection IP 65 -
Temperature range -10 / +40 (+60)
2)
°C
Operating sound pressure level < 70 dB(A)
Cycles per hour 9 (2,7)
1)
h
-1
Max. holding torque 200 Nm
Max. load 2500 N
Manual force emergency manual operation 92 N
1) Specification in ( ) according to EN 60335-2-103.
2)
When using a temperature range of +40°...+60°C use half of maximum cycles per hour.
