GFA 10004010 10013 - Motor Connection; Limit Switch Connection

14
6 Motor connection
M1 Motor
X13 Motor plug
7 Limit switch connection
BANA101101_Z001
S10
14
63
52
3
4
1
2
5
6
A
B
RS 485
A/D
MC
21
22
23
24
25
26
41
36
X12
W3
ws
br
gn
ge
gr
rsl
14
63
52
4
3
6
5
2
1
S10 Emergency manual operation
X12 DES connection
1 Safety circuit
2 Channel B (RS485)
3 Ground
4 Channel A (RS485)
5 Safety circuit
6 Supply voltage
W3 Connection cable freqency inverter
(FI)
