6
2 Technical data
Designation
Unit
Output speed 80 rpm
Output torque 140 (140)
1)
Nm
Output / hollow shaft 25,40 mm
Series SG 50 -
Limit switch range
(maximum revolutions of the output / hollow shaft)
40 -
Supply voltage 1N~ 230 V
Operating current 6,60 A
Operating frequency 50/60 Hz
Power factor cos φ 0,47 -
Safety circuit 24 V
Degree of protection IP 65 -
Temperature range +5 / +40 (+60)
2)
°C
Operating sound pressure level < 70 dB(A)
Output speed OPEN 10-80 min
-1
Output speed CLOSE 10-30 min
-1
Output speed CLOSE > 2,5 m 10-30 min
-1
Cycles per hour 12 (8,5)
1)
h
-1
Max. holding torque 600 Nm
Max. load 6000 N
1) Specification in ( ) according to EN 60335-2-103.
2)
When using a temperature range of +40°...+60°C use half of maximum cycles per hour.
